3105 aluminium sheet for food can
3105 aluminium sheet for food can
alloy 8011 &3105 & 5052
aluminium printed sheet for pilfer proof caps
1. Alloy: 8011, 3105
2. Temper: H14, H16
3. Pattern: rolled, degreased, pre-lubricated, pre-treated, lacquered
4. Thickness: 0.17-- 0.25mm
5. Width: 400 ~ 1000mm
6. Length: 500 ~ 1000mm
7.. Origin: China
High temperature resistant without any distortion and color change;
The paint won't peel off during production;
Tensile Strength: 140-145mpa
Yield Strength: 136-137;
Elongation: 2.5-3.0%;
Earing Rate: <2%;
It's the best material for medicine/wine caps;
Small order is acceptable.
Payment Terms: 30% by TT in advance as deposit and 70% balance by TT or L/C at sight;
Lead Time: Within 20 days after receiving deposit
Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Al | |||||
8011 | 0.5~0.9 | 0.6~1.0 | 0.1 | 0.2 | 0.05 | 0.05 | - | 0.1 | 0.08 | Remains | ||||
3105 | 0.6 | 0.7 | 0.3 | 0.3~0.8 | 0.2~0.8 | 0.2 | - | 0.4 | 0.1 | Remains | ||||
Mechanical Property for Continuous Casting | ||||||||||||||
Alloy | Temper | Thickness (mm) | U.T.S (Mpa) | Elongation (%) | ||||||||||
8011 | H14 | 0.17~0.25 | 185~205 | >=2.5 | ||||||||||
Mechanical Property for Direct Casting | ||||||||||||||
Alloy | Temper | Thickness (mm) | U.T.S (Mpa) | Elongation (%) | ||||||||||
8011 | H14 | 0.17~0.25 | 135~155 | >=2 | ||||||||||
TOLERANCE
Thickness | Width | Length | Squareness |
±0.005mm | ±0.05mm | ±0.05mm | ≤0.3mm |
