dos treatment aluminium sheet

dos treatment alumnium sheet for ropp caps
alloy 8011 &3105 & 5052

aluminium printed sheet  for pilfer proof caps

1.         Alloy: 8011, 3105

2.         Temper: H14,  H16

3.         Pattern: rolled, degreased, pre-lubricated, pre-treated, lacquered

4.         Thickness: 0.17-- 0.25mm

5.         Width: 400 ~ 1000mm

6.         Length: 500 ~ 1000mm

7..         Origin: China

 High temperature resistant without any distortion and color change;

The paint won't peel off during production;

Tensile Strength: 140-145mpa

Yield Strength: 136-137;

Elongation: 2.5-3.0%;

Earing Rate: <2%;

It's the best material for medicine/wine caps;

 Small order is acceptable.

Payment Terms: 30% by TT in advance as deposit and 70% balance by TT or L/C at sight;

Lead Time: Within 20 days after receiving deposit



Chemical Composition limits(WT.%)

Alloy

Si

Fe

Cu

Mn

Mg

Cr


Zn

Ti

Al

8011

0.5~0.9

0.6~1.0

0.1

0.2

0.05

0.05

-

0.1

0.08

Remains

3105

0.6

0.7

0.3

0.3~0.8

0.2~0.8

0.2

-

0.4

0.1

Remains

Mechanical Property for Continuous Casting

Alloy

Temper

Thickness (mm)

U.T.S (Mpa)

Elongation (%)

8011

H14

0.17~0.25

185~205

>=2.5

Mechanical Property for Direct Casting

Alloy

Temper

Thickness (mm)

U.T.S (Mpa)

Elongation (%)

8011

H14

0.17~0.25

135~155

>=2

                  TOLERANCE

Thickness

Width

Length

Squareness

±0.005mm

±0.05mm

±0.05mm

≤0.3mm
